Reintjes introduces down-angle gearbox

The new series comprises sizes WVSA 340, WVSA 740, and WVSA 1540 and is available at a power range from 250 to 3,250 kW and a reduction ratio of 1.5 to 4.

One important feature of the new series includes aluminium housing and the shaft angle of 8° to 10° that is essential for down angle gearboxes.

The down angle prototype gearbox successfully completed its first test runs at the Reintjes facility. The conical spur gears, that generate a shaft angle of 8° to 10° between the input and output shaft, were especially put through intensive testing.

One benefit to installing a down angle gearbox is that the engine room can be engineered in a space-saving design. This is because it allows for horizontal installation of the main engine while the propeller shaft is sloped downwards by the inclination angle inside the gearbox allowing for a shorter propeller shaft.

During the gearbox’s development, special attention was paid to the teeth design and contact pattern under load in order to reduce noise emissions.
