Unison commissions tube bending machine
The machine is capable of generating over 360,000 Nm of torque and can bend piping up to eight inches NPS – with an outside diameter of 8.625 inches or 219.1mm – with Schedule 80 wall thicknesses of 0.5 inch (12.7 mm).
Unison says the availability of all-electric, servomotor-controlled bending machines for pipes of this size brings significant productivity benefits to the fabrication of a ship’s pipework compared with conventional hydraulically-powered machinery.
These include smart software-controlled set-up and right-first-time precision bending – with good accuracy and repeatability. Bend precision is aided by the inclusion of a unique laser-based system that automatically measures and adjusts bend angles for spring-back of the pipe metal.
Newport News Shipbuilding, a division of Huntington Ingalls Industries, is a supplier of nuclear-powered aircraft carriers and submarines to the US Navy. The company has more than seven years of experience using Unison all-electric tube benders, first using the technology back in 2007 when it took delivery of three Unison machines to help fabricate tubing and piping systems for use on aircraft carrier projects.
